Nuvo-7160GC系列: 一般 B key Supported NVIDIA ® RTX™ Supported Supported 802.3at Supported 2.5" SATA硬盘 风扇设计 USB 3.2 Gen1 -25°C to 60°C 64GB Intel 9th/8th-Gen
Specifications
|
|
| 强固型GPU人工智能工控机，支持120W NVIDIA® GPU和第九代/第八代Intel英特尔®酷睿™处理器 | |
| 是 | |
| 240 mm (W) x 225 mm (D) x 111 mm (H) | |
| 4.5 Kg (including CPU, GPU, memory and HDD) | |
| - | |
|
Supporting Intel® 8th-Gen Coffee Lake CPU (LGA1151 socket, 35W/ 65W TDP) - Intel® Core™ i7-8700/ i7-8700T - Intel® Core™ i5-8500/ i5-8500T - Intel® Core™ i3-8100/ i3-8100T - Intel® Pentium® G5400/ G5400T - Intel® Celeron® G4900/ G4900T |
|
| Intel® Q370 Platform Controller Hub | |
| Integrated Intel® UHD Graphics 630 | |
| Up to 64 GB DDR4 2666/ 2400 SDRAM (two SODIMM slots) | |
|
Optional IEEE 802.3at PoE+ PSE for Port 3 ~ Port 6 100 W total power budget |
|
| 6x Gigabit Ethernet ports by 1x I219 and 5x I210 | |
|
1x VGA connector, supporting 1920 x 1200 resolution 1x DVI-D connector, supporting 1920 x 1200 resolution 1x DisplayPort connector, supporting 4096 x 2304 resolution |
|
|
2x software-programmable RS-232/422/485 ports (COM1/ COM2) 2x RS-232 ports (COM3/ COM4) |
|
| 1x 3.5 mm jack for mic-in and speaker-out | |
| - | |
| 2x internal SATA port for 2.5" HDD/SSD installation, supporting RAID 0/ 1 | |
| 1x full-size mSATA port (mux with mini-PCIe) | |
| - | |
| - | |
| 1x full-size mini PCI Express socket with internal SIM socket (mux with mSATA) | |
| - | |
| 1x PCIe x16 slot@Gen3, 16-lanes PCIe signals in Cassette for installing an NVIDIA® graphics card up to 120W TDP (Max. graphics card dimension is 188 mm(L) x 121 mm(W), dual slot allocation) | |
| 1x 3-pin pluggable terminal block for 8~35VDC DC input | |
| - | |
| - | |
|
With 35W CPU and 120W GPU -25°C ~ 60°C ** With 65W CPU and 120W GPU -25°C ~ 60°C */** (configured as 35W TDP) -25°C ~ 50°C */** (configured as 65W TDP) |
|
| CE/FCC Class A, according to EN 55032 & EN 55024 | |
|
4个USB3.1二代(10 Gbps)接口 4个USB3.1一代(5 Gbps)接口 |
|
| 支持 | |
| 1个M.2 2242 B key插槽，提供前面板可插拔的双SIM卡槽，可支持带M.2 LTE模块的双SIM模式 | |
| 2022-10-20 |
